Lazer Lamps Grille Kit Triple-r 750 Elite Land Rover Defender (2020+)

Lazer Lamps Grille Kit Triple-r 750 Elite Land Rover Defender (2020+)

Regular price £732.00 Sale

Lazer Lamps Grille Kit Triple-r 750 Elite Land Rover Defender (2020+)

For an OE quality, auxiliary LED driving light installation, the Lazer Grille Integration Kits include bespoke mounting brackets which allow for quick and easy fitting of Lazer High Performance LED Spotlights within the front grille of the most popular road cars, pick-up trucks, and light commercial vehicles. Designed to blend seamlessly within the original styling of each vehicle, the resulting lighting setup remains fully robust and secure, with extra protection against theft.

The Land Rover Defender kit, designed for MY20 vehicles onwards, includes a pair of Triple-R 750 (Standard Or Elite) High Performance LED driving lights, plus wiring kit, alongside 4x brackets precision-engineered to engage perfectly with the standard lower grille on the vehicle, with added strength and security provided by the supplied self-tapping, anti-theft screws. Made from a composite material, known for its excellent strength and UV stability, the brackets are fully weather and chemical resistant to ensure your installation remains in great condition year after year.

Supplied alongside the mounting brackets are a set of cutting guides, designed to facilitate the installation and ensure a perfect fit everytime.

The Land Rover Defender (2020+) Grille Integration Kit is optimised for use with Triple-R 750 High Performance LED driving lights. Our warranty does not cover grille mounts which are fitted with non-Lazer Lamps’ branded products.

Where the vehicle has automatic high beam assist, and/or LED Matrix headlight system as standard, it may not be possible to detect a 12V high beam signal. In these instances it will be necessary to complete the electrical installation using a Lazer CAN Interface. For advice on how to check for a 12V high beam signal, please click here.
PRODUCT FEATURES

Bespoke vehicle integration kit for Lazer LED Spotlight installation

Custom fit for Land Rover Defender (2020+)

Designed for use with Triple-R 750 High Performance LED Spotlights

Added option for white or amber position/side light function (Standard model only)

Kit also includes bespoke mounting brackets and two-lamp wiring kit

Brackets made from high strength, UV -stable, composite material

Fully road-legal

5-year warranty

Made in Britain

Technical Specifications
  2x
Triple-R
750 Wide
2x
Triple-R 750

2x
Triple-R
750 Elite
(E-Boost Mode)

Voltage Range (DC) 10-32V 10-32V 10-32V
LED Life 50,000 hrs 50,000 hrs 50,000 hrs
Weight 2 kg 2 kg 2 kg
HIGH BEAM FUNCTION
Total Luminous Flux 8640 Lm 9240 Lm

10136 Lm

Total Driver 'FOV' Flux † 5266 Lm 5572 Lm 6680 Lm
Colour Temperature 5000K 5000K 5000K
Number of High Output LEDs 2 x 4 2 x 4 2 x 4
Power Consumption 88 Watts 88 Watts 104 Watts
Current Draw (at 14.4V) 6.2 Amps 6.2 Amps 7.2 Amps
CERTIFICATION
High Beam ECE R149 ECE R112 ECE R112
ECE Reference 20 x2 35 x2

N/A
(12.5 x2 - E-Mark Mode)

Position Light (White only) N/A ECE R7 N/A
PHOTOMETRIC DATA
Horizontal Beam Angle 40o 19° 42°
0.25 lx Line 829m 1225m 1358m
0.5 lx Line 587m 866m 960m
1 lx Line 415m 612m 679m
3 lx Line 239m 354m 392m

† Driver FOV flux is a measure of effective lumens taking consideration of the amount of light in a driver's 'field-of-view' defined as an area +/- 45o left/right, and +/- 10o up/down. For more information – click here.

What's Included
  • 1x Grille Mounting Kit (Includes cutting guides)
  • 2x Triple-R 750 Elite
  • 1x Two-Lamp Wiring Kit
  • Installation Instructions
